DISCO
THE ULTRA-THIN, FRONTAL MOUNT BUTTON
DISCO is the newest ultra-thin button by DMG, featuring round shape, 16mm thickness and clean design. A perfect match for the Greta series.
DISCO AT A GLANCE
Low profile (H=16mm) button & indicator
Frontal mount with back fixing ring
Stainless steel pressel with Braille
Round st/steel surround
Single illumination : red, blue, white
A CLOSER LOOK
The button is available with symbol and halo both illuminated OR with illuminated halo and not illuminated symbol.
Same lettering and symbols available as the Macro button
Frontal mounting technology ensures quick fastening to the faceplate by jam-nut, saving you maintenance time and making it easier to be efficient. Both the button and the hall lantern are H16 fitting ultra-slim plates.
GREAT CONTRAST, BETTER VISIBILITY
The EN81-70:2018 norm requires that luminance contrast between adjacent surfaces shall be evaluated in numerical light reflectance value (LRV).
When mounted on a stainless steel faceplate, the black metal ring added around the DISCO button provides enhanced luminance contrast to the surrounding faceplate.
FRONTAL MOUNTING
Frontal mounting technology ensures quick fastening to the faceplate by jam-nut, saving you maintenance time and making it easier to be efficient.
Both the button and the hall lantern are low profile fitting ultra slim plates, like the Greta landing plates.
The DISCO button can be mounted on 0,7mm up to 3mm thick plates (2mm max for main floor buttons).
The outer ring and the button pressel are both made of stainless steel.
SINGLE LIGHTING
WHICH ELECTRONICS?
Screw terminals
contact module
Sutable on low profile operating panels for screw terminal blocks connection to electronic controllers.
It requires conventional wiring during installation.
Only 1 contact available.
JST connector
contact module
Best solution for pre-wired fixtures, namely our Pitagora System.
A JST cable must be added to connect the push-button.
TOOLS
Lettering
